Material of Arm Construction:
- Carbon Steel / Aluminum - Carbon Steel - Stainless Steel
Optional Accessories:
• Ball valve
• Arresting device for Filling
• Drip bucket
• Up/Down Swtich
• Orientation Switch
• Stand Post / Wall plate
• Locking device (Parking position)
• Junction Box
• Sliding datum bracket with overfill device
• Heating Systems
(Other accessories available on request)
Inlet Flange:
- ANSI 150 & 300 lbs / EN PN16 & 40
Seals:
- Viton
- PTFE
- *More options upon request
Balancing Method:
- Spring Cylinder
Design Pressure:
- 16 bar to 40 bar
Design Temperature:
- Design Temperature: max. -50°C / +250°C
(Exact Temperature ranges dependent on material and Product application)
